Welded Members are assemblies that can contain vendor
components such as handrailing, steel members sections like a steel section,
plates or connection assemblies.
Everything associated with Members are covered under the
Members Toolbar - Click the link to view details TSDMembers Toolbar
Welded Members are always 12 characters in length and are
sub-assemblies in Area Assemblies.
An Example would be:
Where 9999-AA is the Area Assembly.
And
999-AACM001 is an example of a Welded Member Assembly.
There are a series of typical shortcuts
to the library such as Frames, Beams, Columns, etc. for accessing the Welded
Members library faster
Examples of Welded Members are:
Columns
Beams
Vendor
Equipment
Members can be Welded Members like a beam,
with plates welded to it or it can be a Sketch Driving Part, a complete Member with
Connections or a welded frame like a conveyor.
